F254 Dual Row 04 to 80 Contacts SMT Type
- 0.1”(2.54mm) Female Header
- Dual Row 04 to 80 Contacts
- SMT Type Profile: 3.55mm
Specification:
- Current Rating : 3Amp
- Insulator Resistance : 1000 Megohms min.
- Contact Resistance : 20 Milliohms Max.
- Dielectric Withstanding : AC 500V
- Operating Temperature : -40°C ~ +105°C
- Max Processing Temp : 230°C For 30~60 Seconds (260°C For 10 Seconds)
- Contact Material : Phosphor Bronze
- Insulator Material : Polyester, UL 94V-0
- Standard : Nylon-6T & LCP
- Contact Plated : Full Gold, Full Tin, Selective Plated
- Standard : Gold Flash all Over Nickel.
