F209 Single Row 02 to 40 Contacts Straight Type
- 0.1”(2.54mm) Female Header
- Single Row 02 to 40 Contacts
- Straight Type Elevated
Specification:
- Current Rating : 3Amp
- Insulator Resistance : 1000 Megohms min.
- Contact Resistance : 20 Milliohms Max.
- Dielectric Withstanding : AC 500V
- Operating Temperature : -40°C ~ +105°C
- Contact Material : Phosphor Bronze
- Insulator Material : Polyester, UL 94V-0
- Standard : P.B.T
- Contact Plated : Full Gold , Full Tin, Selective Plated.
- Standard : Gold Flash all Over Nickel
